More Versatility and Flexibility than Any Other Ironworker on the Market!

With a 65-ton punching capacity, this ironworker can punch 1-1/16" hole through 3/4" thick, 65,000 tensile plate. It has the largest flat bar shear capacity and the largest angle shear capacity of any machine in its class. Combining this machine's large capacity with its large open tool table makes this machine the most versatile and flexible machine on the market.

A six inch angle shear comes standard and is located in our unique tool table area. This versatile workstation allows additional tooling to be quickly & easily swapped in and out so you can customize the machine to fit your needs.

This American-made ironworker is built tough and utilizes a hydraulic system with electric valve & remote foot pedal for ease of use, an adjustable electric stroke control with scale, and is backed by Scotchman’s industry leading 3-Year Warranty and lifetime customer support!

STD Features

  • Single Operator, 4 Stations
  • 65 Ton punch station
  • Keyed punch ram for safety
  • Punch gauging table with fence and scale
  • Die holder complete with 2" die insert
  • Punch nut with wrench & stripper
  • One round punch & die: max. diameter 1-1/4"
  • Jog control
  • Adjustable electric stroke control with scale
  • Electric remote foot pedal
  • Flat bar shear with 4-way reversible blade
  • Shear table with miter fence
  • Angle shear
  • Tool table work area
  • LED work lights now standard equipment!
  • Slug receptacle
  • Two-stage hydraulic pump
  • Electrical box supplied with emergency palm button and lock-out tag-out accommodations
  • All guards necessary to comply with ANSI B11.5 safety standards
  • Forklift accommodations
  • Warranty: Three years on parts
  • Made in USA

Optional Tooling:

Rod Shear-9 cavity XL
Pipe Notcher - All IW Models
Picket tool
Unistrut Shear
Weld Coupon Bender - XL models
Punch Table Ext. - XL models
SPECIAL Custom Tooling
24" x 5' Conveyor with Angle Iron Support - XL Models
Multi-Loc Punch Gauging Table - 36" & 85" extensions - XL Models
Brake Table w/Scale & Squaring Arm - XL models - XL Models - 12" & 24" brakes
Hydraulic Hold Down
Unequal Leg Angle Shear Blades
Offset Die Holder - XL Models
Urethane Stripper - XL Models
Channel Shear - XL Models
12" Brake - XL Models
Laser Light - Bar Shear - XL models
48" Back Gauge
90° V-Notcher - XL Models
Rectangle Notcher - 65, 90, 120
Open End Brake - XL Models
Econ P&D Package - XL Models
Dlx P&D Pack - XL Models
24" Brake - XL Models
Square Tube Shear - XL Models
Brake Length Gauge w/Scale - ALL Models
LED Lights - XL models
