Scotchman Industries

9012

Visit this product here: https://www.scotchman.com/ironworker/view/9012

Description

Ideal for medium to larger metal fabrication businesses! With its 120-ton punch station this ironworker can punch a 1-1/8" hole in 1" thick, 65,000 tensile mild steel.

The 9012-24M ironworker features a flat bar shear that is 24" wide with bar shear blades that can be rotated four times for maximum blade life. The angle shear, like all Scotchman angle shears, is designed to give a distortion free cut. The 9012 hydraulic ironworker has the same large tool table design as the 6509 model, allowing for quick and easy change of optional tooling giving you the ability to customize this machine to fit your needs! This machine has the capability to accept additional equipment such as press brakes, rod shear, tube shear, picket tool, as well as custom-built tooling.

This American-made ironworker is built tough and utilizes a hydraulic system with electric valve & remote foot pedal for ease of use, an adjustable electric stroke control with scale, and is backed by Scotchman’s industry leading 3-Year Warranty and lifetime customer support!

STD Features

  • Single Operator, 4 Stations
  • 90 Ton punch station
  • Keyed punch ram for safety
  • Punch gauging table with fence and scale
  • Die holder complete with 2" die insert
  • Punch nut with wrench & stripper
  • One round punch & die: max. diameter 1-1/4"
  • LED work lights now standard equipment!
  • Jog control
  • Adjustable electric stroke control with scale
  • Electric remote foot pedal
  • Angle shear
  • Flat bar shear with 4-way reversible blade
  • Shear table with miter fence
  • Tool table work area
  • Slug receptacle
  • Two-stage hydraulic pump
  • Electrical box supplied with emergency palm button and lock-out tag-out accommodations
  • All guards necessary to comply with ANSI B11.5 safety standards
  • Forklift accommodations
  • Warranty: Three years on parts
  • Made in USA

Optional Tooling:

Rod Shear-9 cavity XL
Pipe Notcher - All IW Models
Picket tool
Unistrut Shear
Weld Coupon Bender - XL models
Tool Table Ext - XL models
Punch Table Ext. - XL models
SPECIAL Custom Tooling
24" x 5' Conveyor with Angle Iron Support - XL Models
Multi-Loc Punch Gauging Table - 36" & 85" extensions - XL Models
Brake Table w/Scale & Squaring Arm - XL models - XL Models - 12" & 24" brakes
Hydraulic Hold Down
Unequal Leg Angle Shear Blades
Offset Die Holder - XL Models
Urethane Stripper - XL Models
Channel Shear - XL Models
12" Brake - XL Models
Laser Light - Bar Shear - XL models
48" Back Gauge
90° V-Notcher - XL Models
Angle Shear Miter Guide
Open End Brake - XL Models
Econ P&D Package - XL Models
Dlx P&D Pack - XL Models
24" Brake - XL Models
Square Tube Shear - XL Models
Brake Length Gauge w/Scale - ALL Models
