Automatic CNC Saw for Nonferrous

Precision CNC controlled upcut saw for cutting large capacity aluminum, plastic, or non-ferrous profiles at 90°. Fits almost any profile.

GAA-600 CNC

Select Option

Description
Standard Features
Capacities & Specs

This large capacity up-cut saw features a 600 mm (24") diameter carbide tipped blade for cutting nonferrous materials at 90° up to 8" square or round and 14" x 4" rectangle and fits almost any profile. The precise CNC control stores 10 programs, with each program containing up to 30 different cut lengths and quantities, which can easily be created or adjusted right on the machine at any time. Programs can also be imported through USB port.

The saw uses a robust shuttle feed design with a 27" ballscrew servomotor automatic feeder with unlimited stroke, and adjustable cutting and feeding speeds provide more versatility to customize the saw's operation to fit specific requirements. Three horizontal & three vertical pneumatic clamps secure the workpiece during the cutting process for high cut length tolerances, ±0.006" per index.

This sawing system is built for industrial use and includes a 2-year warranty and lifetime customer support.

Large capacity non ferrous saw
Automatic or Semi-automatic operation
Shuttle feed design cuts at 90 degrees only
Precision CNC controls
Unlimited stroke
Adjustable cutting & feeding speeds
Drill & Tap feature (optional)
Three horizontal pneumatic clamps
Three vertical pneumatic clamps
Powered hood lift
LED lighting
Mist coolant lubrication system
Emergency stop button
One gallon coolant
One 600 mm diameter carbide blade
One blade wrench
Air hose
Base designed as a chip collection with two chip extraction ports
Adjustable leveling pads
Meets CE standards
Warranty: Two years on parts
Made in Spain

Maximum Cutting Capacities (NF) (Non-Ferrous & PVC)	Round Square Rectangle	90 Degree 8" 8" x 8" 14" x 4"
Length Tolerance	±0.006" per index
Cutting Speed	3,000 RPM
Motor Rate	7.5 HP	5.59 kW
Motor Options (Factory Wired)	Specify: 230/460v, 3ph
Air Pressure	90 psi
Maximum Diameter Blade	600 mm
Arbor Bore	50 mm
Width	75"	191 cm
Depth	60"	152 cm
Height (top of hood)	65"	165 cm
Height (floor to table)	38-5/8"	98 cm
Shipping Weight (may vary)	1,750 lbs.	794 kg
